PRACTILITE 802


Offering power, versatility, compact size, and advanced technology features, the Practilite 802 Bi-Color Weather-Resistant Smart LED Panel is an ideal choice for location, studio, ENG, EDU, and rental use.

kinotehnik practilite802 practilite 802 ledpanel led panel dmx weatherproof location lights outdoors batteryoperated v-lock snapbag dopchoice
kinotehnik practilite802 practilite 802 ledpanel led panel dmx weatherproof location lights outdoors batteryoperated v-lock snapbag dopchoice

Brightest Half Panel On The Market


1858 fc / 20,000 Lux at 3.3′ / 1 m

2 hours worktime with 90Wh battery at 90% intensity
4 hours worktime with 150Wh battery at 90% intensity

BATTERY RUNTIME SPEC

Unstoppable Location Light


Imperviousness to inclement weather. IP54 rated LED panel for extreme weather conditions in every environment.

Its IP (Ingress Protection) rating means it’s water resistant and doesn’t have to be safety-bagged in the rain, nor sandstorms or snow.

kinotehnik practilite802 practilite 802 ledpanel led panel dmx weatherproof location lights outdoors batteryoperated v-lock snapbag dopchoice
kinotehnik practilite802 practilite 802 ledpanel led panel dmx weatherproof location lights outdoors batteryoperated v-lock snapbag dopchoice

Color Temperature 3000 – 6000 Kelvin


Color temperature is variable from 3000 to 6000K to meet any ambient light challenge, match other fixtures, or for creative expression.

Remote Control App


Practilite Remote Control app is available for iPhones and iPads that lets you control its functions with your iOS or Android device.

Adjust brightness, color temperature and identify connected fixtures for ease of use and convenient operation, intuitive graphic user interface (GUI) that permits brightness and color control of up to six fixtures (including Practilite Fresnels) at distances up to 30′.

wedding filmmakers light led practilite best weddingfilm weddinglights kinotehnik 602 practilite602
kinotehnik practilite802 practilite 802 ledpanel led panel dmx weatherproof location lights outdoors batteryoperated v-lock snapbag dopchoice

From Soft To Hard Light


The 802 has a super bright, 30° beam spread, that’s ideal for selective lighting and it also comes with unbreakable half and full diffusers for situations where wider coverage is needed.

Practilite 802 LED Power Panel with built in 30 degree lens
Tilt lock for adjusting and locking the tilt angle
Light stand receiver, accepts 5/8” (16mm) BabyPin/Spigot
Diffuser holder (2x). Attach and fix the bottom one first
Thumbscrew (2x) for locking the diffuser holder
 Prism half diffuser
 Full soft diffuser

200 High CRI LED’S


The panel employs 200 LEDs to output the equivalent of an 800W tungsten fixture while consuming just 90W of power.

The power output is linear regardless of color temperature, while the CRI/TLCI rating also remains consistent at 97, an indication of accuracy in color rendition.

kinotehnik practilite802 practilite 802 ledpanel led panel dmx weatherproof location lights outdoors batteryoperated v-lock snapbag dopchoice
kinotehnik practilite802 practilite 802 ledpanel led panel dmx weatherproof location lights outdoors batteryoperated v-lock snapbag dopchoice

Dead Quiet Passive Cooling


The 802 is also seen but not heard. Its fanless cooling system is dead quiet, an important quality in sound-sensitive environments like interviews.

Power Everywhere


The fixture runs on DC with the included universal (100-240 VAC) adapter. You can also run the fixture on 14-28 VDC batteries with an optional V-Lock or Gold Mount battery plate. DMX adapters and SmartSync cables are sold separately.

V-LOCK BATTERY PLATE
G-MOUNT BATTERY PLATE
IP WEATHERPROOF BATTERY PLATE

kinotehnik practilite802 practilite 802 ledpanel led panel dmx weatherproof location lights outdoors batteryoperated v-lock snapbag dopchoice
kinotehnik practilite802 practilite 802 ledpanel led panel dmx weatherproof location lights outdoors batteryoperated v-lock snapbag dopchoice

All In One Location Kit


The Practilite 802 LED Bi-Color LED panel Deluxe Kit with barndoors, AC/DC adapters and diffusers in NANUK930 case is a great choice for videographers and filmmakers who need a fast set-up with flexible color temperature on the location or in the studio.

A hard shipping Nanuk 930 case in graphite color is included for protection when traveling or storage.

Keyboard


 On/Off switch with safety delay
➒ “Set” key for toggling between color temperature and output
 3200/5600K preset for fast setup
 “+/-” values of given mode

How to dial-in the DMX base channel?
On the fixture interface side, press and hold down the upper button/key for few seconds
use the potentiometer knobs to dial in the desired DMX base channel.

“Using Practilites has significantly increased the quality of our work and production value being on set. We’ve used the Practilite 802 on dozens of productions, both commercial and creative. Their products are easy to use, intuitive and innovative; making lighting a scene easier and faster. “

Danny Bou - ORIGINFILMS

F E A T U R E S

Kinotehnik Practilite Fresnel LED kit 602 604
3 x Practilite 602 KIT
19/02/2020

Practilite 802 RED

950.001,289.00

(Excl. VAT)

✅ In Stock

Offering power, versatility, compact size, and advanced technology features, the Practilite 802 Bi-Color Water-Resistant Smart LED Panel is an ideal choice for live-broadcast, ENG, and rental use.

PRACTILITE802 USER MANUAL

Key Features:
Color Temperature: 3000-6000K
High CRI: 97
20.000 lux @ 1m
Remote Control App
30° Beam Spread
Includes 60 and 90° Diffusers
0 to 100% Dimming
Size: 14.5 x 8.7 x 2
IP54 weatherproof rating
Included 100 to 240 VAC adapter
External battery option



Clear
SKU: PRACT802 Category:



The well-crafted, all-aluminum 14.5 x 8.7 x 2″ (30 x 15 x 6 cm) compact panel employs 200 LEDs to output the equivalent of an 800W Tungsten fixture while consuming just 90W of power. The Practilite 802 has a medium, 30° beam spread that’s ideal for selective lighting but it comes with unbreakable half and full diffusers for situations where wider coverage is needed – making it one of the most versatile LED panels on the location lighting market today.

Tune color balance or brightness
From tungsten to daylight and any lighting situation in between, you just dial in the matching color balance and tune the brightness manually or from your smartphone. Sophisticated software ensures that power output is linear regardless of color temperature, while the CRI rating also remains consistent at 97, an indication of accuracy in color rendition. Light intensity is variable from 5% to 100% and can be adjusted locally on the fixture or even via DMX.

Flicker-free: Ready for slo-mo
The Practilite 802 is flicker-free, which allows for perfectly lit slow-motion shots.

A further indication of versatility is the panel’s power options. The light can run on AC worldwide with the included 100 to 240 VAC adapter or on batteries with the purchase of an optional V-Lock or G-Mount for situations where the mains power is unavailable. Power, compact size, versatility, and advanced technology make the Practilite 802 a smart choice.

IN THE BOX:

  • Practilite 802
  • 60° Diffuser (1pc) Half diffusion
  • 90° Diffuser (1pc) Full diffusion
  • Diffuser holders (2pc) with 2x M6 thumbscrews
  • 110-220V AC/DC adapter with 3m cord
  • User manual
Weight 6 kg
Output

20`000 lux @1m (30 degree beam), 5500 lux @ 80°, fully diffused

Color Balance

3000K to 6000K. Presets @ 3200K and 5600K.

CRI

≤97

Power Consumption

90W max, 14-28V AC, can be battery operated

Wireless Control

Via "Practilite" App: Intensity and Color Balance

DMX512

Yes, via optional Y cable adapter

Cooling

Silent, passive cooling

Weatherproof

Weather protection IP54 rating. Weatherproof, usable in all conditions (Not submersible!)

Physical dimensions

14.5 x 8.7 x 2.5“ / 30 x 15 x 6 cm , "Half panel" form factor
